CRL Oil Rubbed Bronze Geneva 3-Point Movable Square Style Transom Clamp

Finish/Color : Oil Rubbed Bronze
Item #: GTC0370RB
View Prices with a Purchase Account
Minimum Order Quantity : 1
Unit of Measure : each

Shipping Weight : 1.42 Pounds
Shipping Limitations : None
Compliance and Restrictions
Warning Reproductive Harm - www.p65warnings.ca.gov
CRL Oil Rubbed Bronze Geneva 3-Point Movable Square Style Transom Clamp
×
CRL Oil Rubbed Bronze Geneva 3-Point Movable Square Style Transom Clamp
Quantity Standard Price Sale Price Your Price
CRL Oil Rubbed Bronze Geneva 3-Point Movable Square Style Transom Clamp Stock
Branch Location STOCK AVAILABILITY
Los Angeles, California 12
Dallas, Texas 6/21/2024
Chicago (Elgin), Illinois 6/17/2024
San Francisco/Oakland (Union City), California 6/20/2024
Atlanta, Georgia 6/24/2024
New York Area (Secaucus, New Jersey) 6/24/2024
Boston (Taunton), Massachusetts 2
Orlando, Florida 6/25/2024
Denver, Colorado 6/25/2024
Seattle (Kent), Washington 6/25/2024
Cleveland (Solon), Ohio 6/24/2024
Philadelphia Area (Moorestown, New Jersey) 6/21/2024
Phoenix, Arizona 6/20/2024
Las Vegas, Nevada 6/20/2024
Houston, Texas 2
Miami, Florida 6/25/2024
San Diego, California 6/19/2024
Carolinas and Virginia, South Carolina 6/25/2024
Product details
  • Back Plate
    Full
  • Edge Profile
    Square
  • Finish/Color:
    Oil Rubbed Bronze
  • Glazing Thickness
    3/8 in. (10 mm)
  • Height
    2-3/16 in. (56 mm)
  • Material
    Brass
  • Maximum Door Width - 2 Hinges
    28
  • Mounting Type
    Ceiling Mount
  • Series
    Geneva
  • Width
    3-1/2 in. (89 mm)
Product Overview
  • Mounts to Ceiling Instead of Traditional Side Mounting Application
  • Three Stopping Points Include 45 Degrees Out, Closed Position, and 45 Degrees In
  • Stocked in Five Popular Finishes
  • Use Monolithic Tempered Glass

Our CRL 3-Point Movable Transom Clamps provide design alternatives to the traditional side mounted "teeter-totter" application. Mounted to the ceiling instead of the sides of the transom allows more glass exposure. The Clamps will hold at 45 degrees inward, at the closed position, and at 45 degrees outward. The square or beveled appearance matches many of our popular Hinge Series. Accommodates 1/2", 3/8", and 5/16" (12, 10, and 8 mm) thick tempered glass.

SPECIFICATIONS:
  • Glass Thickness: 5/16" to 1/2" (8 to 12 mm)
  • Material: Solid Brass
  • Includes: Gaskets, Mounting Screws, Phillips Screws,
  • Allen Screws, and Glass Fabrication Dimensions
  • Gaskets are included for 3/8" and 1/2" (10 and 12 mm) glass only. If using 5/16" (8 mm) glass, Cat. No. GEN13 Gaskets must be ordered.
    Cut-Out Required

    NOTE: Maximum transom size is 28" W x 12" H (711 x 305 mm). Two Clamps must be used per transom. It is recommended to come in 6" (152 mm) to the center of the cutout for each Clamp.
