CRL 695 Series Brushed Stainless Anodized Drop Ceiling Mount Sliding Door Kit with Softbrake Braking System

  Item number CRL495DBSA was replaced by item number CRL695DBSA.
Finish/Color : Brushed Stainless Anodized
Brushed Stainless Anodized
Item #: CRL695DBSA
View Prices with a Purchase Account
Minimum Order Quantity : 1
Unit of Measure : each

Shipping Weight : NA
Shipping Limitations : No UPS - Common Carrier Only
Compliance and Restrictions
Warning Reproductive Harm - www.p65warnings.ca.gov
CRL 695 Series Brushed Stainless Anodized Drop Ceiling Mount Sliding Door Kit with Softbrake Braking System
×
CRL 695 Series Brushed Stainless Anodized Drop Ceiling Mount Sliding Door Kit with Softbrake Braking System
Quantity Standard Price Sale Price Your Price
CRL 695 Series Brushed Stainless Anodized Drop Ceiling Mount Sliding Door Kit with Softbrake Braking System Stock
Branch Location STOCK AVAILABILITY
Los Angeles, California 17
Dallas, Texas 6/28/2024
Chicago (Elgin), Illinois 6/28/2024
San Francisco/Oakland (Union City), California 6/27/2024
Atlanta, Georgia 7/1/2024
New York Area (Secaucus, New Jersey) 1
Boston (Taunton), Massachusetts 6/28/2024
Orlando, Florida 7/2/2024
Denver, Colorado 7/2/2024
Seattle (Kent), Washington 7/2/2024
Cleveland (Solon), Ohio 7/1/2024
Philadelphia Area (Moorestown, New Jersey) 6/28/2024
Phoenix, Arizona 6/27/2024
Las Vegas, Nevada 6/27/2024
Houston, Texas 6/28/2024
Miami, Florida 7/2/2024
San Diego, California 6/26/2024
Carolinas and Virginia, South Carolina 7/2/2024
Product details
  • Finish/Color:
    Brushed Stainless Anodized
  • Glazing Thickness
    3/8 To 1/2 in. (10 To 12 mm)
  • Track Length
    118 in. (2997 mm)
Product Overview
  • Kits Intended for 3/8" To 1/2" (10 To 12 mm) Tempered Glass
  • Can Accommodate Properly Installed Doors Weight Up to 330 Pounds (150 kg)
  • Rollers Have Up to 1/4" (6 mm) of Vertical Adjustment to Aid in Door Alignment After Installation
  • Track Length is 118" (3 m)
  • Use Monolithic Tempered Glass

CRL 690 Series Sliding Door Kits are available in wall mount, ceiling mount, and drop ceiling mount models, with or without a sidelite and with or without the "Softbrake" braking system. All come with everything you need except the tempered glass and pull hardware. Kits are available in satin anodized, brushed stainless anodized, and matte black finishes with a special order option to clad or powder paint in many architectural finishes. Contact CRL Technical Sales for Commercial Products for kit selection or installation assistance.


Minimum sliding panel width of 34-1/4" (800 mm) for control in single or both directions.

Kit Contains:
  • 118"(3m) of CRL4933EXT Track kit
  • 118" (3m) of CRL6979A Bottom Channel
  • Glazing Vinyl for 3/8" To 1/2" (10 To 12 mm) Glass
  • 1 Set CRL6939 Top Hangers
  • 1 Set CRL6942 Roller Stops
  • 1 Each CRL2940 Bottom Guide
  • 1 Set CRL2945 Door Edge Guards
  • 1 Set CRL2929 Dropped Ceiling Adapter Bracket
  • 1 Each CRL695SBK Softbrake Kit

    Most shipping weights are approximate and have not been verified. If the exact weight is needed in order to determine shipping costs, and shipping costs are required in order for you to complete your order, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer's video card and on how your monitor's color is adjusted.

  • Technical References & CAD Drawings
