No longer available.

CRL-Blumcraft® Satin Anodized 337 Series 2" Diameter Extruded Aluminum Cap Rail

 Discontinued item. All sales are final.
No longer available.
Finish/Color : Satin Anodized
Item #: 337SA
View Prices with a Purchase Account
Minimum Order Quantity : 1
Unit of Measure : Stock Length

Shipping Weight : NA
Shipping Limitations : No UPS - Common Carrier Only
Compliance and Restrictions
Warning Reproductive Harm - www.p65warnings.ca.gov
CRL-Blumcraft® Satin Anodized 337 Series 2" Diameter Extruded Aluminum Cap Rail
CRL-Blumcraft® Satin Anodized 337 Series 2" Diameter Extruded Aluminum Cap Rail
Quantity Standard Price Sale Price Your Price
CRL-Blumcraft® Satin Anodized 337 Series 2" Diameter Extruded Aluminum Cap Rail Stock
Los Angeles, California Ask Us 800.421.6144
Dallas, Texas Ask Us 800.421.6144
Chicago (Elgin), Illinois Ask Us 800.421.6144
San Francisco/Oakland (Union City), California Ask Us 800.421.6144
Atlanta, Georgia Ask Us 800.421.6144
New York Area (Secaucus, New Jersey) Ask Us 800.421.6144
Boston (Taunton), Massachusetts Ask Us 800.421.6144
Orlando, Florida Ask Us 800.421.6144
Denver, Colorado Ask Us 800.421.6144
Seattle (Kent), Washington Ask Us 800.421.6144
Cleveland (Solon), Ohio Ask Us 800.421.6144
Philadelphia Area (Moorestown, New Jersey) Ask Us 800.421.6144
Phoenix, Arizona Ask Us 800.421.6144
Las Vegas, Nevada Ask Us 800.421.6144
Houston, Texas Ask Us 800.421.6144
Miami, Florida Ask Us 800.421.6144
San Diego, California Ask Us 800.421.6144
Carolinas and Virginia, South Carolina Ask Us 800.421.6144
Product details
  • Diameter
    2 in. (51 mm)
  • Finish/Color:
    Satin Anodized
  • Glass Pocket Width
    3/4 in. (19 mm)
  • Glazing Insert
  • Glazing Thickness
    9/16 in. (14 mm)
  • Length
    120 in. (3048 mm)
  • Material
    6063-T5 Aluminum
  • Top of Rail to Top of Glass Pocket
Product Overview
  • For 1/2" (12 mm) Glass
  • Ready-to-Install
  • Extruded Heavy-Duty Solid Aluminum Construction
  • Two Architectural Finishes, Plus Mill Aluminum Available from Stock
  • Stainless Steel Adapter Strips Sold Separately
  • Sold in 120" (3.05 m) Stock Lengths or Custom Fabricated to Size

CRL-Blumcraft®'s top quality American made extruded Cap Rails are produced from 6063-T5 aluminum and are offered in two architectural finishes, plus mill aluminum. Cap Rails are sold in stock lengths or can be custom fabricated to size. The use of stainless steel Adapter Strips, Very High Bond Tape, and Splice Pins are required during the installation process.

When using CRL-Blumcraft®'s 337 and 338 Series Cap Rails, it is important to install the stainless steel Adapter Strips onto the glass edge with Very High Bond Cladding Tape before installing your Cap Rail.

NOTE: Each Cap Rail comes complete with pre-drilled holes 24" (610 mm) on center with set screws along one side of the Cap Rail for proper attachment to the Adapter Strips.

Most shipping weights are approximate and have not been verified. If the exact weight is needed in order to determine shipping costs, and shipping costs are required in order for you to complete your order, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer's video card and on how your monitor's color is adjusted.

Technical References & CAD Drawings
