CRL Oil Rubbed Bronze Hydroslide Bi-Fold Glass-to-Glass Hinge

Finish/Color : Oil Rubbed Bronze
Substitutions: HYDH0370RB
Item #: HYDH1800RB
View Prices with a Purchase Account
Minimum Order Quantity : 1
Unit of Measure : each

Shipping Weight : 3.2 Ounces
Shipping Limitations : None
Compliance and Restrictions
Warning Reproductive Harm - www.p65warnings.ca.gov
CRL Oil Rubbed Bronze Hydroslide Bi-Fold Glass-to-Glass Hinge
×
CRL Oil Rubbed Bronze Hydroslide Bi-Fold Glass-to-Glass Hinge
Quantity Standard Price Sale Price Your Price
CRL Oil Rubbed Bronze Hydroslide Bi-Fold Glass-to-Glass Hinge Stock
Branch Location STOCK AVAILABILITY
Los Angeles, California 124
Dallas, Texas 4/5/2024
Chicago (Elgin), Illinois 4/5/2024
San Francisco/Oakland (Union City), California 4/4/2024
Atlanta, Georgia 4/8/2024
New York Area (Secaucus, New Jersey) 4/8/2024
Boston (Taunton), Massachusetts 4/8/2024
Orlando, Florida 4/9/2024
Denver, Colorado 4/9/2024
Seattle (Kent), Washington 4/9/2024
Cleveland (Solon), Ohio 4/5/2024
Philadelphia Area (Moorestown, New Jersey) 4/5/2024
Phoenix, Arizona 4/4/2024
Las Vegas, Nevada 4/4/2024
Houston, Texas 4/5/2024
Miami, Florida 4/9/2024
San Diego, California 4/3/2024
Carolinas and Virginia, South Carolina 4/9/2024
Product details
  • Edge Profile
    Beveled
  • Finish/Color:
    Oil Rubbed Bronze
  • Glass To Glass Angle
    180
  • Glazing Thickness
    5/16 in. To 3/8 in. (8 mm To 10 mm)
  • Material
    Brass
  • Maximum Door Weight - 2 Hinges
    100 lbs. (45.4 kg)
  • Maximum Door Width
    24 in. (610 mm)
  • Series
    Hydroslide
Product Overview
  • Wall Mount and Glass-to-Glass Models Allow Door to Bi-Fold Into Enclosure
  • Used in Conjunction With Hydroslide Upper Track, One Hanger, and Upper Track Connectors
  • Four Finishes to Match Our Hydroslide System Hardware
  • Use Monolithic Tempered Glass

CRL Hydroslide Bi-Fold Hinges add a different element to the already popular Hydroslide System. Instead of a standard sliding door, you can now "Bi-Fold" two sliding panels of glass into the shower enclosure, creating a larger opening than the single sliding door will allow. Made of solid brass and available in four popular finishes, the Hydroslide Bi-Fold Hinges require holes in the glass.

NOTE: Upper Track, Hanger, and 90 Degree Wall-to-Upper Track Connectors necessary for installation are all sold separately.

SPECIFICATIONS:
Glass Thickness: 5/16" to 3/8" (8 to 10 mm) Tempered Safety Glass
Construction: Solid Brass
Hinge Swings: Bi-Fold into Shower Enclosure
Closing Type: Free Swinging
Holes Required in Glass
Includes: Gaskets, Screws, and Glass Fabrication Dimensions
Maximum Capacities: Do not Exceed Either 48" (1.22 m) or 100 Lbs. (45 kg) for Both Folding Doors Combined. Use Two Hinges Only on Each Folding Panel.

Product Warning:

CRL Shower Door Hinges are designed for residential or hotel shower use. If hinges are to be used for other than their intended purpose, approval must be obtained from the CRL Shower Door Technical Sales Department.

Use only the template included with this hinge. Cut-out dimensions for CRL hinges may not match those of other brands.

Most shipping weights are approximate and have not been verified. If the exact weight is needed in order to determine shipping costs, and shipping costs are required in order for you to complete your order, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer's video card and on how your monitor's color is adjusted.

Technical References & CAD Drawings
