CRL Brushed Nickel 72" Vienna Hinge Kit

Finish/Color : Brushed Nickel
Item #: V1E03372BN
View Prices with a Purchase Account
Minimum Order Quantity : 1
Unit of Measure : each

Shipping Weight : 9.81 Pounds
Shipping Limitations : UPS Oversize Rate
Compliance and Restrictions
Warning Reproductive Harm - www.p65warnings.ca.gov
CRL Brushed Nickel 72" Vienna Hinge Kit
×
CRL Brushed Nickel 72" Vienna Hinge Kit
Quantity Standard Price Sale Price Your Price
CRL Brushed Nickel 72" Vienna Hinge Kit Stock
Branch Location STOCK AVAILABILITY
Los Angeles, California 7
Dallas, Texas 5
Chicago (Elgin), Illinois 5/23/2025
San Francisco/Oakland (Union City), California 5/22/2025
Atlanta, Georgia 5/26/2025
New York Area (Secaucus, New Jersey) 1
Boston (Taunton), Massachusetts 5/26/2025
Orlando, Florida 5/27/2025
Denver, Colorado 1
Seattle (Kent), Washington 5
Cleveland (Solon), Ohio 5/26/2025
Philadelphia Area (Moorestown, New Jersey) 5/23/2025
Phoenix, Arizona 5/22/2025
Las Vegas, Nevada 5/23/2025
Houston, Texas 5
Miami, Florida 5/28/2025
San Diego, California 5/21/2025
Hauppauge In Other Service Center
Carolinas and Virginia, South Carolina 1
Product Details
  • Finish/Color:
    Brushed Nickel
  • Glazing Thickness
    1/2 in. (12 mm)
  • Length
    72 in. (1829 mm)
  • Material
    Aluminum
  • Maximum Clamping Screw Torque
    60 lbf.in (677.9 cN.m)
  • Maximum Door Weight
    100 lbs. (45.4 kg)
  • Maximum Door Width - 1/2 Glass
    30 in. (762 mm)
  • Maximum Door Width - 3/8 Glass
    36 in. (914 mm)
  • Mounting Type
    Wall Mount
  • Self-Centering
    Yes
  • Series
    Vienna
Product Overview
  • 72" (1.83 m) High Vienna Series Kit
  • Includes Hinges, Extrusion and Vinyl Seal
  • Heavy-Duty Hinge Kit 3/8" or 1/2" (10 or 12 mm) Glass
  • 5 Degree Hinge Pins Ensure Positive Closure to Provide a Water Resistant Seal at Both the Sides and the Bottom
  • Self-Centering from 15 Degrees
  • Use Monolithic Tempered Glass

CRL Heavy-Duty Kits contain Bottom Sweeps for both 3/8" (10 mm) and 1/2" (12 mm) glass. All Kits can be mounted with the hinge on the left or right hand side when viewed from inside of the shower, and should be installed so that the door swings out.

NOTE: 3/8" Glass maximum door width 36"/914 mm; weight 100 lbs/45 kg and 1/2" Glass maximum door width 30"/762 mm; weight 100 lbs (45 kg).

Most shipping weights are approximate and have not been verified. If the exact weight is needed in order to determine shipping costs, and shipping costs are required in order for you to complete your order, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer's video card and on how your monitor's color is adjusted.

Technical References & CAD Drawings
