CRL Standard Size Manual DW Deluxe Service Window Unglazed with S.S.Step-Sill

Finish/Color : Duranodic Bronze
Duranodic Bronze
Item #: DW4836SX0UDU
View Prices with a Purchase Account
Minimum Order Quantity : 1
Unit of Measure : each

Shipping Weight : NA
Shipping Limitations : No UPS - Common Carrier Only
Compliance and Restrictions
Warning Reproductive Harm - www.p65warnings.ca.gov
CRL Standard Size Manual DW Deluxe Service Window Unglazed with S.S.Step-Sill
×
CRL Standard Size Manual DW Deluxe Service Window Unglazed with S.S.Step-Sill
Quantity Standard Price Sale Price Your Price
CRL Standard Size Manual DW Deluxe Service Window Unglazed with S.S.Step-Sill Stock
Branch Location STOCK AVAILABILITY
Los Angeles, California 2
Dallas, Texas 4/5/2024
Chicago (Elgin), Illinois 4/5/2024
San Francisco/Oakland (Union City), California 4/4/2024
Atlanta, Georgia 4/8/2024
New York Area (Secaucus, New Jersey) 4/8/2024
Boston (Taunton), Massachusetts 4/8/2024
Orlando, Florida 4/9/2024
Denver, Colorado 4/9/2024
Seattle (Kent), Washington 4/9/2024
Cleveland (Solon), Ohio 4/5/2024
Philadelphia Area (Moorestown, New Jersey) 4/5/2024
Phoenix, Arizona 4/4/2024
Las Vegas, Nevada 4/4/2024
Houston, Texas 4/5/2024
Miami, Florida 4/9/2024
San Diego, California 4/3/2024
Carolinas and Virginia, South Carolina 4/9/2024
Product details
  • Deal Tray Included
    No
  • Finish/Color:
    Duranodic Bronze Anodized
  • Frame Depth
    4 in. (101.6 mm)
  • Glazed
    No
  • Glazing Thickness
    1/4 in. (6 mm)
  • Height
    36 in. (914.4 mm)
  • Latch Type
    Self Latching
  • Material
    Aluminum
  • Screen
    No
  • Security Feature
    Latching Handle
  • Sill Height
    1-1/2 in. (38.1 mm)
  • Usage
    Interior,Exterior
  • Width
    48 in. (1219.2 mm)
Product Overview
  • Ships Assembled and Unglazed, Vinyl for 1/4" or 1/2" Glass
  • XO Clerkside (X=sliding panel)
  • Sturdy Self-Latching Handle
  • Popular 47-1/2" W x 35-3/4" H Frame Size fits 48" x 36" Opening
  • S.S.Step-Sill with Water Dam, Manual Open/Manual Close

CRL Standard Size Manual Deluxe Service Windows ship fully assembled, ready to glaze or factory glazed and ready to install. They are designed for heavy-duty commercial use such as drive-thru or walk-up service and are also ideal for interior applications needing enhanced security and performance.


Standard size models are available in Satin Anodized or Duranodic Bronze finish. Different models are available with two types of bottom condition: half-track (no track under sliding panel for clear passage across counter by others) or stainless steel step-sill, with water-dam for exterior applications.
CRL also quotes custom versions of these high-quality, popular windows.

CRL DW standard size models that ship unglazed come with two sets of glazing vinyl: one for ¼” glass, and one for ½” glass (the larger vinyl will also accept 9/16” glazing).

For 5/8” glazing vinyl (5/8” is maximum glass thickness for glazing a DW window with vinyl), CRL product # WV3865 can be ordered separately. It is sold by the foot, minimum order 100 feet.

For 3/8” glass, the provided ½” vinyl can be used if the edges of the glass are wrapped with CRL product # 982116X34GRY double-sided adhesive foam tape, with the backing left on the outer edge that enters the glazing vinyl channel. It is sold separately in 200-foot rolls.

Glass sizes for CRL DW standard size models with 47-1/2” W x 35-3/4” H frame size and a stainless-steel step-sill, are 21-3/8” W x 30-15/16” H (two pieces same size).

Product Warning:

Heavy Duty Service Windows; not designed to be primary building seal for severe weather conditions.

Most shipping weights are approximate and have not been verified. If the exact weight is needed in order to determine shipping costs, and shipping costs are required in order for you to complete your order, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer's video card and on how your monitor's color is adjusted.

Technical References & CAD Drawings
