CRL Polished Chrome Glass Door Pivot Hinges

Finish/Color : Polished Chrome
Item #: EH224
View Prices with a Purchase Account
Minimum Order Quantity : 1
Unit of Measure : Pack

Shipping Weight : 8.0 Ounces
Shipping Limitations : None
Compliance and Restrictions
Warning Reproductive Harm - www.p65warnings.ca.gov
CRL Polished Chrome Glass Door Pivot Hinges
×
CRL Polished Chrome Glass Door Pivot Hinges
Quantity Standard Price Sale Price Your Price
CRL Polished Chrome Glass Door Pivot Hinges Stock
Branch Location STOCK AVAILABILITY
Los Angeles, California 118
Dallas, Texas 5
Chicago (Elgin), Illinois 4/26/2024
San Francisco/Oakland (Union City), California 4/25/2024
Atlanta, Georgia 4/29/2024
New York Area (Secaucus, New Jersey) 15
Boston (Taunton), Massachusetts 4/29/2024
Orlando, Florida 2
Denver, Colorado 4/30/2024
Seattle (Kent), Washington 4/30/2024
Cleveland (Solon), Ohio 4/26/2024
Philadelphia Area (Moorestown, New Jersey) 4/26/2024
Phoenix, Arizona 4/25/2024
Las Vegas, Nevada 4/25/2024
Houston, Texas 4/26/2024
Miami, Florida 2
San Diego, California 121
Carolinas and Virginia, South Carolina 1
Product details
  • Finish/Color:
    Polished Chrome
  • Glazing Thickness
    1/4 in. To 5/16 in. (6mm To 8 mm)
  • Height
    1-1/16 in. (27 mm)
  • Material
    Brass
  • Maximum Door Width
    14 in. (355.6 mm)
  • Pack Quantity
    2
  • Weight Capacity
    18 lbs. (8.2 kg)
  • Width
    1-9/16 in. (39.7 mm)
Product Overview
  • No Holes or Cut-Outs Required
  • Available in Several Finishes
  • For 1/4" to 5/16" (6 to 8 mm) Glass
  • Easy-to-Install

The maximum recommended door width is 14" (356 mm) for Standard Hinges and 20" (508 mm) for Wide Hinges. Maximum weight should not exceed 18 lbs. (8.2 kg) for Standard Series and 28 lbs. (12.7 kg) for Wide Series. Minimum required clearance is 3/16" (5 mm) top and bottom. One set top and bottom per pack.

Product Warning:

If the size of the glass door exceeds 14" (356 mm) wide and 20 Lbs. (9 kg) total weight. Please use Cat. No. EH324 Hinge, which is heavier duty.

Most shipping weights are approximate and have not been verified. If the exact weight is needed in order to determine shipping costs, and shipping costs are required in order for you to complete your order, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer's video card and on how your monitor's color is adjusted.

Technical References & CAD Drawings
Installation Instructions
