• Automatically Maintains the Load Position Without Using Latches
• Reduces Hazards of Lifting Loads From Upright Racks
• 300 lbs. (135 kg) Lifting Capacity

This CRL Wood's Powr-Grip® DC Powered 2 Pad Quadra Tilt Lifter features an innovative four-bar tilt mechanism that significantly reduces the effort of tilting loads between flat and upright positions. This tilt mechanism also reduces hazards associated with lifting loads from upright racks: When a load is tilted to either the upright or the flat position, the vacuum lifter maintains the load position automatically without using latches, eliminating the tendency for a load to "kick back" at the operator's knees. For special sizes and capacities, please contact our Glass and Glazing Technical Sales.


SPECIFICATIONS:

Standard Vacuum Pad Spread: 11" x 24" (279 x 610 mm)

Number/Size of Vacuum Pads: 2/10" (254 mm) Diameter Lipped Vacuum Pads

Lifting Capacity: 300 pounds (135 kg)

Standard Operating Power:
120 volts AC, 60 hertz, 3 amps
(240 volts AC, 50/60 hertz, 2 amps also available)

Alternative Power Systems:
DC power system (MTA2HV11DCS)
Air (venturi) power system (MTA2HV11A1R)

Apply: 2 sec. Release: 2 sec. (approx.)

Load Movement: Assisted Manual Tilt, 90 degrees between upright and flat

Standard Features:
Vacuum Gauge
Vacuum Line Filter
Twist-Lock Electrical Plug
Blow-Off for Quick Release

Available Options:
G-Force™ Hoist Control (Cat. No. 1H0HGP)
Vacuum Loss Warning Buzzer (Cat. No. E03VLW)
Closed Cell Foam Pad Rings (Cat. No. FRHV11)
Voltage Adaptation (Cat. No. E06VA)
