CRL 695 Series Matte Black Drop Ceiling Mount Sliding Door Kit with Softbrake Braking System

Finish/Color : Matte Black
Satin Anodized
Brushed Stainless Anodized
Matte Black
Item #: CRL695DMBL
View Prices with a Purchase Account
Minimum Order Quantity : 1
Unit of Measure : each
Where to buy

View Technical References
Shipping Weight : 0.16 Ounces
Shipping Limitations : None
Compliance and Restrictions
Warning Reproductive Harm - www.p65warnings.ca.gov
CRL 695 Series Matte Black Drop Ceiling Mount Sliding Door Kit with Softbrake Braking System
×
CRL 695 Series Matte Black Drop Ceiling Mount Sliding Door Kit with Softbrake Braking System
Quantity Standard Price Sale Price Your Price
CRL 695 Series Matte Black Drop Ceiling Mount Sliding Door Kit with Softbrake Braking System Stock
Branch Location State STOCK AVAILABILITY
Kent Washington Ask Us 1.800.421.6144
Saint Peters Missouri Ask Us 1.800.421.6144
Secaucus New Jersey 2
Solon Ohio Ask Us 1.800.421.6144
Union City California Ask Us 1.800.421.6144
Rock Hill South Carolina Ask Us 1.800.421.6144
Hauppauge New York Ask Us 1.800.421.6144
San Diego California Ask Us 1.800.421.6144
Atlanta Georgia Ask Us 1.800.421.6144
Orlando Florida 2
Moorestown New Jersey Ask Us 1.800.421.6144
Phoenix Arizona Ask Us 1.800.421.6144
Los Angeles California 16
Denver Colorado Ask Us 1.800.421.6144
Sunrise Florida 1
Elgin Illinois 1
Taunton Massachusetts Est. Availability 2026-05-13
Fairfield Ohio Ask Us 1.800.421.6144
Dallas Texas Ask Us 1.800.421.6144
Tampa Florida Ask Us 1.800.421.6144
Las Vegas Nevada Ask Us 1.800.421.6144
Houston Texas Ask Us 1.800.421.6144
Product Details Product Overview Technical References & CAD Drawings
Product Details
  • Finish/Color:
    Matte Black
  • Glazing Thickness
    3/8 in. To 1/2 in. (10 mm To 12 mm)
  • Track Length
    118 in. (3000 mm)
Back to Top
Product Overview
  • Kits Intended for 3/8" To 1/2" (10 To 12 mm) Tempered Glass
  • Can Accommodate Properly Installed Doors Weighing Up to 330 Pounds (150 kg)
  • Roller Have Up to 1/4" (6 mm) of Vertical Adjustment to Aid in Door Alignment After Installation
  • Track Length is 118" (3 m)
  • Use Monolithic Tempered

CRL 690 Series Sliding Door Kits are available in wall mount, ceiling mount, and drop ceiling mount models, with or without a sidelite and with or without the "Softbrake" braking system. All come with everything you need except the tempered glass and pull hardware. Kits are available in satin anodized, brushed stainless anodized, and matte black finishes with a special order option to clad or powder paint in many architectural finishes. Contact CRL Technical Sales for Commercial Products for kit selection or installation assistance.


Minimum sliding panel width of 30-7/8" (785 mm) for control in a single direction: 42-1/2" (1080 mm) for control in both directions. Existing CRL690 Series installations can be easily upgraded by ordering kits.

Kit Contains:
  • 118" (3m) of CRL4932EXT Track Set
  • 1 Set CRL6939 Top Hangers
  • 1 Set CRL6942 Roller Stops
  • 1 Each CRL2940 Bottom Guide
  • 1 Set CRL2945 Door Edge Guards
  • 1 Set CRL2929 Dropped Ceiling Adapter Brackets
  • 1 Each CRL695SBK Softbrake Kit

    Most shipping weights are approximate and have not been verified. If the exact weight is needed in order to determine shipping costs, and shipping costs are required in order for you to complete your order, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer's video card and on how your monitor's color is adjusted.

    • Back to Top
    Technical References & CAD Drawings
    Brochures & Literature
    690 695 Series Sliding Door Product Information
    Installation Instructions
    690 695 Series Grid System Installation Instructions
    695 Series Sliding Door Installation Instructions
    Specifications
    690 695 Series Sliding Door System 3-Part Spec
    CAD Drawings - pdf
    690 695 Series Sliding Door System CAD Drawings.pdf
    CAD Drawings - dwg
    690 695 Series Sliding Door System CAD Drawings.dwg
