CRL Dark Bronze 1900 Series Non-Handed Rim Panic Exit Device

Finish/Color : Dark Bronze
Item #: 1900BRZ
View Prices with a Purchase Account
Minimum Order Quantity : 1
Unit of Measure : each

Shipping Weight : 8.0 Pounds
Shipping Limitations : None
Compliance and Restrictions
Warning Reproductive Harm - www.p65warnings.ca.gov
CRL Dark Bronze 1900 Series Non-Handed Rim Panic Exit Device
×
CRL Dark Bronze 1900 Series Non-Handed Rim Panic Exit Device
Quantity Standard Price Sale Price Your Price
CRL Dark Bronze 1900 Series Non-Handed Rim Panic Exit Device Stock
Branch Location STOCK AVAILABILITY
Los Angeles, California 2
Dallas, Texas 2
Chicago (Elgin), Illinois 3
San Francisco/Oakland (Union City), California 11/14/2024
Atlanta, Georgia 11/18/2024
New York Area (Secaucus, New Jersey) 1
Boston (Taunton), Massachusetts 11/18/2024
Orlando, Florida 11/19/2024
Denver, Colorado 1
Seattle (Kent), Washington 11/19/2024
Cleveland (Solon), Ohio 11/18/2024
Philadelphia Area (Moorestown, New Jersey) 11/15/2024
Phoenix, Arizona 2
Las Vegas, Nevada 1
Houston, Texas 1
Miami, Florida 11/20/2024
San Diego, California 1
Carolinas and Virginia, South Carolina 2
Product details
  • Door Thickness
    1-3/4 in. (44.5 mm)
  • Faceplate Style
    Radius Weatherstripped
  • Finish/Color:
    Dark Bronze
  • Handing
    Non Handed
  • Includes
    Mounting Hardware
  • Material
    Steel
  • Minimum Stile Width
    1-3/4 in. (44.5 mm)
  • Model
    1900
  • Panic Bar Base Height
    data
  • Panic Bar Projection
    2-3/4 in. (69.9 mm)
  • Panic Bar Width Net
    42-1/2 in. (1079.5 mm)
  • Panic Dogging
    Standard Hex Key Dogging
  • Panic Head Base Width
    1-1/8 in. (28.6 mm)
  • Panic Head Height
    4-5/8 in. (117.5 mm)
  • Panic Type
    Rim Exit Device
  • Push Pad Width
    22 in. (558.8 mm)
  • Recommended Door Type
    Narrow, Medium, Wide Stile, Aluminum, Wood, Hollow Metal
  • Replacement Parts
    DL2170SCKDDU, DL2170Y8KDDU
  • Similar
    311295C4313
  • UL Listed
    Yes
Product Overview
  • For Use with 1-3/4" Narrow Stile, Medium, and Wide Stile Aluminum Doors, Wood or Hollow Metal Doors
  • Concealed Fastening for Added Security
  • Non-Handed and Reversible
  • UL Listed

These CRL 1900 Series Narrow Stile Panic Exit Devices are designed for 1-3/4" (44.5 mm) narrow stile aluminum doors, but can also be used with medium and wide stile aluminum, wood or hollow metal doors. The base is field sizeable, and fits doors 30" to 44" (762 to 1118 mm) wide and 1-3/4" (44.5 mm) thick. Ruggedly constructed with 3/4" (19 mm) throw cast brass latch bolt. Surface mounted adjustable roller strike included. This device is non-handed and is easy-to-install. For keyed entry, an optional Cat. No. DL911SC Series, or other brand, Rim Cylinder is required.

Most shipping weights are approximate and have not been verified. If the exact weight is needed in order to determine shipping costs, and shipping costs are required in order for you to complete your order, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer's video card and on how your monitor's color is adjusted.

Technical References & CAD Drawings
