• Tested and Listed to UL Standard 1034 for Safety
• Fail-Safe Lock Requires Power to Remain Locked
• Dual Monitoring Lock and Door Status
• 12 VDC Input
• Selectable Locking Time

This CRL Electric Solenoid Bolt Lock is "UL" listed for life safety and features an adjustable 0 to 5 second locking delay, dual lock and door monitoring capability, and 12 VDC input voltage.


A brushed stainless cover plate is included.

SPECIFICATIONS:
Indoor Use Only
Input: 12 Volts DC
Solenoid: Continuous Duty
Current Draw: .9 A Start / .3 A Standby

DIMENSIONS:
Cutout: 8" x 1-3/8" x 1-5/8"D (200 x 35 x 43D mm)
Face: 7-7/8" x 1-5/16" x 1/8" (200 x 34 x 3 mm)
Cover Plate: 8-5/8" x 1.5" (219 x 38 mm)
Strike: 3-1/2" x 15/16" x 1-1/16"D (90 x 24 x 27D mm)

Product Warning:

THE SUPPLIED STRIKE PLATE MUST BE INSTALLED TO ACTIVATE THE LOCK SOLENOID. THIS LOCK WILL NOT THROW THE LATCH BOLT UNLESS IT SENSES THAT THE DOOR IS N THE CLOSED POSITION
